Home Solar Power System Grid Inverter
Products Description
|
Model No(TL)
|
NTS
1000
|
NTS
1500
|
NTS
2200
|
NTS
3000
|
NTS
3600
|
NTS
4400
|
NTS
5000
|
NTS
6000
|
|
DC Side / Input Parameters
|
||||||||
|
Max DC power (W)
|
1500
|
2250
|
3300
|
4500
|
5400
|
6600
|
7500
|
7500
|
|
Max DC voltage (Vdc)
|
400
|
400
|
450
|
|||||
|
Min System start/Shut down voltage (Vdc)
|
75/100
|
|||||||
|
MPPT voltage range(Vdc)
|
100-400
|
100-450
|
||||||
|
Max. input current (A)
|
13
|
|||||||
|
Number of MPP trackers
|
1
|
2
|
||||||
|
Strings per MPP tracker
|
1
|
|||||||
|
AC Side / Output Parameters
|
||||||||
|
Nominal output power (W)
|
1000
|
1500
|
2200
|
3000
|
3600
|
4000
|
5000
|
6000
|
|
Maximum output power (W)
|
1100
|
1650
|
2420
|
3300
|
3960
|
4400
|
5500
|
6600
|
|
Nominal output voltage/range (V)
|
208,220,230,240/180~270
|
|||||||
|
AC grid frequency/range (Hz)
|
50Hz,60Hz(auto-selection) / 44Hz-55Hz; 54Hz-65Hz
|
|||||||
|
AC connection (with PE)
|
Single phase
|
|||||||
|
Maximum output current (A)
|
6
|
8
|
12
|
16
|
16
|
21
|
23
|
26
|
|
Current distortion(THDi)
|
<1.5%
|
<2.5%
|
||||||
|
Power factor
|
~1%(Adjustable from 0.8 leading to 0.8 lagging)
|
|||||||
|
Efficiency
|
||||||||
|
Maximum conversion efficiency
|
97.3%
|
97.3%
|
97.4%
|
97.5%
|
97.8%
|
97.8%
|
97.5%
|
97.6%
|
|
European efficiency
|
97.0%
|
97.0%
|
97.1%
|
97.2%
|
97.3%
|
97.3%
|
97.2%
|
97.3%
|
|
MPPT efficiency
|
99.9%
|
|||||||
|
Safety and Protection
|
||||||||
|
DC reverse-polarity protection
Anti-islanding / Overvoltage protection Short circuit protection Leakage current protection Grid monitoring / Ground fault monitoring DC/AC side SPD(thermally protected) |
YES
|
|||||||
|
General Parameters
|
||||||||
|
Dimension (L/W/H)(mm)
|
382/317/151
|
382/317/166
|
||||||
|
Weight (kg)
|
10
|
13.5
|
||||||
|
Embedded DC Switch
Night power consumption (W) Isolation type Protection degree Operation temperature ºC Cooling concept Operatiing Altitude (m) Acoustic noise level (dB) Display Communication Warranty |
Optional
< 0.2
Transformerless
IP65 according to IEC60529
-25 ~ +60
Natural convection
<2000m without power derating
< 25
Graphic LCD
Standard WiFi; GPRS/LAN optional
Standard 5 years; 7/10 years optional
|
|||||||
