Wall-mounted Home Energy Storage Solar Energy Storage System 5KW
Product Parameters
|
Items
|
Specifications
|
|
Ratedenergy(kWh)
|
5.12KWh
|
|
Configuration
|
16s1p
|
|
NominalVoltage(V)
|
51.2V
|
|
WorkingVoltage(V)
|
42V~58.4V
|
|
NominalCapacity(Ah)
|
100Ah
|
|
Ratedcharge/discharge Current(A）
|
50A/100A
|
|
Peakchargecurren
|
100A
|
|
Peakdischargecurrent
|
100A
|
|
WorkingTemperature
|
0～55℃(Charge)-10～55℃(Discharge)
|
|
Humidity(%)
|
5~95%
|
|
AltitudeLimited(m)
|
≤2000m
|
|
Weight(Kg)
|
50Kg
|
|
Dimension(mm)
|
655*440*182mm
|
|
Certification
|
UN38.3/UL1973/IEC62619
|
|
weight
|
50kg
|
|
cyclelife
|
≥5000cycles@80%DOD，0.5C/0.5C，25°C
|
|
Numberofmodules
|
1pcs
|
|
Communicationmode
|
CAN&RS485&Dry
|
